SPECIFICATIONS:
GENERAL
Phase
Single Phase
UPS topology
Line-interactive
Energy saving technology
GreenPower UPS™ Bypass Technology
INPUT
Nominal input voltage ( VAC )
230 ± 10%
Input voltage range ( VAC )
170 ~ 290
Input frequency ( Hz )
50 ± 5
60 ± 5
Input frequency detection
Auto-sensing
Rated input current ( A )
10
Input connector type
IEC C14
Detachable power cord plug type
AU x 1
Power cord length (Ft.)
6
Power cord length (M.)
1.8
OUTPUT
Capacity (VA)
2200
Capacity (Watts)
1320
On battery waveform
Simulated Sine Wave
On battery voltage(s) ( VAC )
230 ± 10%
On battery frequency ( HZ )
50 ± 1%
60 ± 1%
Automatic voltage regulation (AVR)
Single Boost, Single Buck
Overload protection
Circuit Breaker
Outlet(s) - total
4
Outlet type
AU x 4
Outlet(s) - battery & surge protected
4
Typical transfer time ( ms )
4
BATTERY
Runtime at half load ( min )
7
Runtime at full load ( min )
1
Typical recharge time ( hours )
8
Start on battery
Yes
User-replaceable
Yes
Battery type
Sealed Lead-acid
Battery cartridge
RBP0086
RBP quantity ( PCS )
2
SURGE PROTECTION AND FILTERING
Surge suppression ( Joules )
125
EMI/RFI filtration
Yes
Phone/network protection RJ11/RJ45 (COMBO)
1-in, 1-out
MANAGEMENT & COMMUNICATIONS
LCD panel
Yes
LCD information display
Operation Type , Power Status , Battery Status , Load Status , Fault & Warning , Other Information
LCD setting & control
Alarm Setting
LED indicators
Power On
HID compliant USB port(s)
1
Serial port
RS232
Audible alarms
Battery Mode , Low Battery , Overload , UPS Fault
Management cable ( pcs )
Power Cord x1 , USB Cable x1 , Phone Line x1
Power management software
PowerPanel® Personal
PHYSICAL
Form factor
Tower
Enclosure construction
Metal
Colour
Black
PHYSICAL SIZE - UPS MODULE
Dimensions (wxhxd) (mm.)
140 x 180 x 326
Weight (kg.)
14.5
ENVIRONMENTAL
Operating temperature (°C)
0 ~ 40
Operating relative humidity (non-condensing) ( % )
0 ~ 90
Operating elevation ( feet/meters )
0-10,000 feet (0-3,000 meters)
Storage temperature (°C)
-20 ~ 50
Storage relative humidity (non-condensing) ( % )
0 ~ 90
Storage elevation ( feet/meters )
0-10,000 feet (0-3,000 meters)
Online thermal dissipation ( BTU/HR )
225
Audible Noise At 1.5m From Surface Of Unit ( DBA )
50
CERTIFICATIONS
Certifications
CE , C-Tick , EAC
ROHS
Yes
|
