Products: |
|
GENERAL
Phase
Single Phase
Form Factor
Tower
UPS Topology
Line-interactive
Energy Saving Technology
GreenPower UPS™ Bypass Technology
Energy Star Qualified
Yes
Active PFC Compatibility
Yes
INPUT
Nominal Input Voltage ( Vac )
230
Input Voltage Range ( Vac )
151 ~ 301
Input Frequency ( Hz )
50 ± 3
60 ± 3
Input Frequency Detection
Auto-sensing
Rated Input Current ( A )
10
Input Connector Type
IEC C14
Detachable Power Cord Plug Type
AU x 1
IEC C14 x 1
Power Cord Length (ft.)
6
6
Power Cord Length (m.)
1.83
1.83
OUTPUT
Capacity (VA)
1500
Capacity (Watts)
1350
On Battery Waveform
Pure Sine Wave
On Battery Voltage(s) ( Vac )
230 ± 5 %
On Battery Frequency ( Hz )
50 ± 1%
60 ± 1%
Power Factor
0.9
Automatic Voltage Regulation (AVR)
Double Boost, Single Buck
Overload Protection
Internal Current Limiting
Outlet(s) - Total
8
Outlet Type
IEC C13 x 8
Outlet(s) - Battery & Surge Protected
8
Outlet(s) - Critical Load (CL)
4
Outlet(s) - Non-Critical Load (NCL)
4
Typical Transfer Time ( ms )
4
BATTERY
Runtime at Half Load ( min )
17
Runtime at Full Load ( min )
4
Typical Recharge Time ( Hours )
8
Quick Recharge Time ( Hours )
3
Start On Battery
Yes
User-replaceable
Yes
Hot-swappable
Yes
Battery Type
Sealed Lead-acid
Battery Cartridge (RBP)
RBP0023
Battery Cartridge (RBP) Quantity ( pcs )
1
SURGE PROTECTION & FILTERING
Surge Suppression ( Joules )
405
EMI/RFI Filtration
Yes
MANAGEMENT & COMMUNICATIONS
LCD Panel
Yes
LCD Types
Detachable LCD Panel
LCD Information Display
Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log
LCD Setting & Control
Mode Setting, Alarm Setting, Input & Output, Battery
Setting, Fault & Warning, Event & Log
LED Indicators
Power On, Line Mode, Battery Mode, UPS Fault, Replace
Battery
HID Compliant USB Port(s)
1
Emergency Power Off (EPO) Port
Yes
Audible Alarms
Battery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs )
Power Cord x2, USB Cable x1, EPO Cable x1
Power Management Software
PowerPanel Business (Recommended)
SNMP/HTTP Remote Monitoring
Yes - with optional RMCARD205
PHYSICAL
Enclosure Construction
Metal
Color
Black
PHYSICAL SIZE - UPS MODULE
Dimensions (WxHxD) (in.)
6.69 x 8.70 x 17.01
Dimensions (WxHxD) (mm.)
170 x 221 x 432
Weight (lbs.)
55.34
Weight (kg.)
25.1
|
$750 (special)
inc GST
|
