General
Topology Line Interactive with Automatic Voltage Regulation
Configuration Tower
Part Number 5E1100iUSB-AU
Rating (VA/Watts) 1000VA/660W
Dimensions (H x W x D, mm) 180 x 133 x 330
Weight (kg) 9.3
Warranty 12 months
Electrical Input
Connection
(1) Aust. 10A
Australian 10A
Input Voltage Range 170- 280V
Nominal Voltage 230 VAC
Operating Frequency 50Hz or 60Hz
Electrical Output
Voltages 230V
Output Receptacles
(3) Aust. 10A
Australian 10A
On Battery Voltage Regulation +/-10%
Output Frequency +/-1 Hz in battery mode
Transfer Time 4-8ms typical, 10ms max.
Battery
Battery Type (2)12V 7Ah
Recharge Time 6 hours to 90% after complete discharge
Communications
LEDs AC Mode: Green LED lighting
Battery Mode: Green LED Flashing
Audible Alarms Five audible alarms for Backup Mode, Low Battery, Overload, Battery replace & Fault
Communication Ports USB port
